RM01029 | Stator for Kawasaki KZ 550 1000 1100 | ZX 550 1100 | Suzuki GSXR 600 750 1000 1980-2005 | OEM# 31401-18G00 21003-1040 |
C$206.89
Dimensions :
Interior Diameter: 28mm
Exterior Diameter: 102mm
Thickness: 20mm
Wires length stator to terminals : 700 mm
Other specifications :
Number of wires :3
Number of plugs: 0
Number of terminals : 3
Wire to wire resistance :
Alternator :White Between each White = 0.4 ohms+/-20%
Alternator : White to Ground = O.L. ON DISPLAY
Brand new aftermarket stator
- You must re-install your original connector and grommet (see picture).
- Once your connector and grommet is re-installed, our part becomes a plug-and-play unit, direct fit, and very easy to install.
- Higher grade of electric components.
- Highest grade copper windings, resistant to 200 degrees Celsius.
- All products shipped are tested
We have even included the opposite connector (main harness side) as we know these are often melted/corroded/defective and a major cause for repetitive electrical issues.
All item pictures are accurate; if in doubt do not hesitate to compare our item to your original part.
Before installing your new stator
- Check the AC output of the stator.
- Replace any burned or corroded connectors on stator and regulator/rectifier
- Check and repair any melted wiring.
- Use hi-temp dielectric grease on all connectors
Our stator may use a different wire color code than your original.
All of the wires are installed in the correct order; please do not change any of the wiring configurations.
This stator is designed as a direct plug-in replacement and should be used as such.
When bolting stator in, always use locking compound.
If our stator includes a pickup coil, always make sure the air gap is correct upon installation; we suggest as close as possible no less than 0.010″.
| Weight | 0.93 kg |
|---|---|
| Dimensions | 16.002 × 6.096 × 12.95 cm |
| Brand |
RMSTATOR |
| Fitment Type |
Guaranteed Fit |
OEM AND OTHER PART NUMBER
OEM PART NUMBER
- 210031013, 210-031-013, 210.031.013, 210 031 013
- 210031038, 210-031-038, 210.031.038, 210 031 038
- 210031040, 210-031-040, 210.031.040, 210 031 040
- 210031256, 210-031-256, 210.031.256, 210 031 256
- 21003-1327, 21003.1327, 21003 1327, 210031327
- 21003-1393, 21003.1393, 21003 1393, 210031393
- 31401-18G00, 31401.18G00, 31401 18G00, 3140118G00
- 31401-29G00, 31401.29G00, 31401 29G00, 3140129G00
- 31401-40F00, 31401.40F00, 31401 40F00, 3140140F00
- 31401-43400 , 31401.43400, 31401 43400, 3140143400
OTHER PART NUMBER
- RM01029
DO NOT MANUFACTURE PARTS, DESIGN PERMANENT SOLUTIONS
We cultivate our actions towards finding permanent solutions. There is no way, us, as customers, would like to replace a part again and again. This mindset forces our team to design to fix, to conquer these pesky electrical failures in powersport.
GOOD DESIGN PRODUCE GOOD PRODUCTS. EFFICIENT DESIGN CREATES STELLAR PRODUCTS.
We are committing to innovate in finding clever ways to design more efficient parts that produce better results than any other part on the market.
WE ALL ARE CUSTOMERS ELSEWHERE.
In our shopping journey for buying our daily goods, we all expect to be treated with respect in a relation that makes us feel welcomed. Our team is encouraged to elevate that standard even higher and to provide all the information necessary for an easy and reliable installation.
OWN YOUR CUSTOMER PAIN LIKE IT IS YOURS
We own powersport rides ourselves. We feel the pain of dealing with unsolvable troubleshooting on our rides. We are committed in manufacturing complete solutions to known or I-would-never-have-suspected issues that are plaguing your rides... and ours.
