RM01213 | Stator for Yamaha SRX 600 SRX 700 Carb L/C 1998 1999 |
C$295.89
Dimensions :
Interior diameter : 42mm
Exterior diameter : 103mm
Thickness : 14mm
Length of wires stator to grommet : 70mm
Length of wires grommet to plug : 155mm
Length of pickup coil’s wire to grommet : 70mm
Other specifications :
Number of wires : 10
Number of plugs : 3
Number of pins : 10
Wire to wire resistance :
Alternator : Yellow to Yellow/Black = 0.4 ohms +/-20%
Pickup : White/Green to White/Red = 200 ohms +/-20%
Source : Brown/Red to Black = 80 ohms +/-20%
Source 2: Black/Red to Brown = 450 ohms +/-20%
Available on backorder
Brand new stator
- Direct replacement to your original unit
- Plug-and-play, direct fit, easy installation.
- Highest grade lamination materials
- Highest grade copper windings, resistant to 200 degrees Celsius.
- Pick up pulsar coil included
- Connector included
- Rubber grommet included
- All products shipped are tested
All item pictures are accurate; if in doubt do not hesitate to compare our item to your original part.
Before installing your new stator
- Check the AC output of the stator.
- Replace any burned or corroded connectors on stator and regulator/rectifier
- Check and repair any melted wiring.
- Use hi-temp dielectric grease on all connectors
Our stator may use a different wire color code than your original. `
All of the wires are installed in the correct order; please do not change any of the wiring configurations.
This stator is designed as a direct plug-in replacement and should be used as such.
When bolting stator in, always use locking compound.
If our stator includes a pickup coil, always make sure the air gap is correct upon installation; we suggest as close as possible no less than 0.010’’.
| Weight | 0.87 kg |
|---|---|
| Dimensions | 16.002 × 6.096 × 12.95 cm |
| Brand |
RMSTATOR |
| Fitment Type |
Guaranteed Fit |
OEM AND OTHER PART NUMBERS
OEM NUMBER:
- 8DF-85510-00-00, 8DF.85510.00.00,8DF 85510 00 00, 8DF855100000
ADDITIONAL NUMBER
- RM01213
