RM22978 | Kit Stator +PeakRPM CDI Box + Ext. Ignition Coil for Ski-Doo Alpine Formula MX / Plus Nordik Safari 1988-90 | 410912500 |
C$506.37
Stator:
Dimensions :
Interior diameter : 43 mm
Exterior diameter : 108 mm
Thickness : 18 mm
Length of wires : 200 mm
Wire to wire resistance :
Alternator : Yellow To Yellow/Brown = 0.4 ohms +/-20%
Source : Black to Black/Red = 78 ohms +/-20%
High performance CDI Box
The only real way to test your CDI box is to swap it out with another known good unit from the same year/make/model. Because of this, we recommend that you rule everything else out before replacing the CDI box.
Available on backorder
Brand New Kit Stator + PeakRPM CDI Box + External Ignition Coil
- The Quality exceeds the OEM equipment
- All shipped products are tested
All item pictures are accurate; if in doubt, do not hesitate to compare our item to your original part.
Brand new stator
- Direct replacement to your original unit
- Plug-and-play, direct fit, easy installation
- Highest grade of lamination materials
- Highest grade of copper winding, resistant to 200 degrees Celsius
- Connector included
- Back Plate included
Brand new PeakRPM CDI Box
- Direct replacement to your original unit
- Plug-and-play, direct fit, easy installation
- Higher grade of electronic components
Brand new external ignition coil
- You must re-install your OEM spark plug cap(s)
- Once your OEM spark plug cap(s) are re-installed, our part becomes a Plug-and-play unit, direct fit, and easy to install
- Highest grade of lamination materials
Before installing your new stator
- Check the AC output of the stator.
- Replace any burned or corroded connectors on stator and regulator/rectifier
- Check and repair any melted wiring.
- Use hi-temp dielectric grease on all connectors
Our stator may use a different wire color code than your original.
All of the wires are installed in the correct order; please do not change any of the wiring configurations.
This stator is designed as a direct plug-in replacement and should be used as such.
When bolting stator in, always use locking compound.
If our stator includes a pickup coil, always make sure the air gap is correct upon installation; we suggest as close as possible no less than 0.010’’.
Before installing your new CDI box
Our CDI may use a different wire color code than your original.
All of the wires are installed in the correct order; please do not change any of the wiring configurations.
This CDI is designed as a direct plug-in replacement and should be used as such.
Before installing your new external ignition coil
- Remove spark plug cap(s) from your OEM external ignition coil.
- Screw cap(s) on the new external ignition coil.
Remove the yellow wire from external the ignition coil, if it is not applicable to your model.
| Weight | 2.15 kg |
|---|---|
| Dimensions | 33.02 × 22.86 × 5.08 cm |
| Brand |
RMSTATOR |
| Fitment Type |
Guaranteed Fit |
OEM AND OTHER PART NUMBER
OEM NUMBER
- RM22978-R00, RM22978 R00, RM22978.R00, RM22978 R00
ADDITIONAL NUMBER
- RM22978
