RM23004 | RMSTATOR New Aftermarket Yamaha Kit High Output Stator 100 W + High Performance CDI Box |
C$508.99
Dimensions High Output Stator :
Interior diameter : 40mm
Exterior diameter : 103mm
Thickness : 17mm
Length of wires stator to grommet : 150mm
Length of wires grommet to plug : 330mm
Length of pickup coil’s wire to grommet : 270mm
Other specifications :
Number of wires : 6
Number of plugs : 3
Number of pins : 3
Wire to wire resistance :
Alternator : Yellow to Black = 0.4ohms +/-20%
Pickup : White/Green to White/Red = 115ohms +/-20%
Source : Green to Red = 22ohms +/-20%
Dimensions CDI Box HP :
Height: 25mm
Length: 87mm
Width: 71mm
Distance between fixation holes: 85mm
Wires length: 140mm
Other specifications:
Number of plugs: 2
Number of pins: 8
Available on backorder
Brand New Kit High Output Stator + PeakRPM CDI Box
- Our part is plug-and-play, direct fit and easy to install
- All shipped products are tested
All item pictures are accurate; if in doubt, do not hesitate to compare our item to your original part.
High Output Stator
- Highest grade of lamination materials
- Highest grade of copper winding, resistant to 200 degrees Celsius
- Pick up pulsar coil included
- Connector included
- Rubber grommet included
- Adjustable timing plate to advance and retard up to 10 degrees included
PeakRPM CDI Box:
- Our PeakRPM CDI Box provides the optimal output for your ride
- Higher grade of electric components, the quality exceeds the OEM equipmentBefore installing your new stator
- Check the AC output of the stator.
- Replace any burned or corroded connectors on stator and regulator/rectifier
- Check and repair any melted wiring.
- Use hi-temp dielectric grease on all connectors
Our stator may use a different wire color code than your original.
All of the wires are installed in the correct order; please do not change any of the wiring configurations.
This stator is designed as a direct plug-in replacement and should be used as such.
When bolting stator in, always use locking compound.
If our stator includes a pickup coil, always make sure the air gap is correct upon installation; we suggest as close as possible no less than 0.010’’.High Performance CDI Box:Our CDI may use a different wire color code then your original.
All of the wires are installed in the correct order; please do not change any of the wiring configurations.
This CDI is designed as a direct plug-in replacement and should be used as such.
| Brand |
RMSTATOR |
|---|---|
| Fitment Type |
Guaranteed Fit |
OEM AND OTHER PART NUMBERS
OTHER PART NUMBER
- RM23004
