RMS010-107367 | Stator for Polaris 850 PRO RMK 155 / 163 / 174 | 850 SKS 146 / 155 | 850 Switchback Assault 144 2019-2024 | OEM# 4017454 |
C$340.89
Dimensions:
Interior diameter: 54 mm
Exterior diameter: 119 mm
Thickness: 20 mm
Length of wires stator to grommet: 630 mm
Length of pickup coil’s wire to grommet #1: 60 mm
Length of pickup coil’s wire to grommet #2: 140 mm
Other specifications:
Number of wires: 8
Number of plugs: 2
Number of pins: 8
Number of poles: 18
Wire to wire resistance:
Alternator: Yellow to Yellow = 0.6 ohms +-20%
Pickup #1: Green to White/Green = 285 ohms +-20%
Pickup #2: White to White/Red = 285 ohms +-20%
Available on backorder
Brand new aftermarket Stator
- You must re-install your original grommet (see picture)
- Once your connector and grommet is re-installed, our part becomes a Plug-and-play unit, direct fit, and very easy to install
- Highest grade of lamination materials
- Highest grade of copper winding, resistant to 200 degrees Celsius
- Two Pick up pulsar coil included
- Connectors included
- All products shipped are tested
All item pictures are accurate; if in doubt, do not hesitate to compare our item to your original part.
Before installing your new stator
- Check the AC output of the stator
- Replace any burned or corroded connectors on stator and regulator rectifier
- Check and repair any melted wiring
- Use hi-temp dielectric grease on all connectors
Our stator may use a different wire color code than your original.
| Weight | 0.45 kg |
|---|---|
| Dimensions | 6.096 × 16.002 × 12.95 cm |
| Brand |
RMSTATOR |
| Fitment Type |
Guaranteed Fit |
OEM AND OTHER PART NUMBER
OEM NUMBER
- 401-7454, 401.7454, 401 7454, 4017454
ADDITIONAL NUMBER
- RMS010-107367
