RMS900-106275 | Kit Stator + Gasket + Mosfet Regulator for Yamaha YFM 550 / 700 Grizzly 2007-2015 | # 3B4-81410-00-00 / 1D7-81960-00-00 |
C$445.37
Dimensions Stator
Interior diameter : 45 mm
Exterior diameter : 106 mm
Thickness : 27 mm
Length of wires stator to grommet : 100 mm
Length of wires grommet to plug : 550 mm & 1100 mm
Length of pickup coil’s wire to grommet : 80 mm
Other specifications :
Number of wires : 5
Number of plugs : 2
Number of pins : 5
Wire to wire resistance :
Alternator : Between each White = 0.4 ohms +/-20%
Alternator : White to Ground = 0.L on Display
Pickup : White to Grey = 500 ohms +/-20%
Dimensions Mosfet Voltage Regulator
Width : 95 mm
Length : 30 mm
Height: 110 mm
Fixation holes center to center :78 mm
Other specifications :
Number of plugs : 2
Number of pins : 5
Minimum Charging Voltage: 14.5 V +/- 0.5 V
Maximum Charging Current: 50 A / 500 W
Open Circuit Voltage: < 15 V
Operation Temperature: -20° to 85°
Available on backorder
Brand new aftermarket Stator + Crankcase cover Gasket + Mosfet Voltage Regulator Kit
- Direct replacement to your original unit
- Plug-and-play, direct fit, easy installation
- All shipped products are tested
All item pictures are accurate; if in doubt, do not hesitate to compare our item to your original part.
Stator
- Highest grade of of lamination materials
- Highest grade of of copper winding, resistant to 200 degrees Celsius
- Stator crankcase cover gasket included
- Pick up pulsar coil included
- Connector included
- Rubber grommet included
Mosfet Voltage Regulator
STOP BURNING YOUR REGULATOR RECTIFIER !
It is time to update or replace your voltage regulator with the advanced MOSFET type.
It runs cooler than all OEM diode style regulators. In addition, this rectifier has overheat protection, rather than burn up it will simply turn off for a while and cool off.
- The quality exceeds the OEM equipment
- Improved heat sink and charging capabilities
- Higher grade of electric components
We have even included the opposite connector (main harness side) as we know these are often melted / corroded / defective and a major cause of repetitive electrical issues.
Battery condition is extremely important. No stator or voltage regulator can work correctly with a bad or weak battery. Always fully charge your battery before performing any charging system tests or replacing parts. If there is any doubt, have the battery load tested or replaced.
| Weight | 1.72 kg |
|---|---|
| Dimensions | 33.02 × 25.4 × 22.86 cm |
| Brand |
RMSTATOR |
| Fitment Type |
Guaranteed Fit |
OEM AND OTHER PART NUMBER
OEM NUMBER
- 106275-R00, 106275.R00, 106275 R00, 106275R00
ADDITIONAL NUMBER
- RMS900-106275
