RMS900-106631 | Kit Stator + CDI Box Ignition Coil Calibration Module for 2-Cyl Ski-Doo RER Skandic / GSX / GTX 1998-2013 | 420886603 |
C$725.78
Stator Dimensions:
Interior diameter : 43 mm
Exterior diameter : 110 mm
Thickness : 32 mm
Length of wires stator to plug : 500 mm
Other specifications :
Number of wires : 7
Number of plugs : 2
Number of pins : 7
Wire to wire resistance :
Alternator : Between each Yellow = 0.4 ohms +/-20%
Alternator: Yellow to Ground = 0.L on display
Source: Red to Black = 8 ohms +/-20%
CDI Box Ignition Coil Calibration Module Dimensions:
Height: 49 mm
Length: 95 mm
Width: 88 mm
Fixation holes center to center: 72 mm
Other specifications:
Number of plugs: 4
Number of pins: 7
Please note that: The only real way to test your CDI box is to swap it out with another known good unit from the same year / make / model. Because of this, we recommend that you rule everything else out before replacing the CDI box.
Brand new aftermarket Stator + CDI Box Ignition Coil Calibration Module Kit
- Direct replacement to your original unit
- Plug-and-play, direct fit, easy installation
- All products shipped are tested
All item pictures are accurate, if in doubt, do not hesitate and compare our item to your original part.
Brand new aftermarket stator
- Highest grade of lamination materials
- Highest grade of copper winding, resistant to 200 degrees Celsius
- Connector included
- Back Plate included
Brand new aftermarket CDI Box Ignition Coil Calibration Module
- Our PeakRPM CDI Box provides the optimal output for your ride
- Higher grade of electronic components
- The Quality exceeds the OEM equipment
- Before installing your new stator
- Check the AC output of the stator
- Replace any burned or corroded connectors on stator and regulator/rectifier
- Check and repair any melted wiring
- Use hi-temp dielectric grease on all connectors
Our stator may use a different wire color code than your original.
| Weight | 1.47 kg |
|---|---|
| Brand |
RMSTATOR |
| Fitment Type |
Guaranteed Fit |
OEM AND OTHER PART NUMBER
OEM NUMBER
- 106631-R00, 106631.R00, 106631 R00, 106631R00
ADDITIONAL NUMBER
- RMS900-106631
