RMS900-106771 | Kit Lighting Stator + Regulator for Honda XR 80 / 100 R | CRF 80 / 100 F 1992-2013 | OEM # 31120-GN1-691 / 31120-KN4-751 |
C$220.78
Stator Dimensions:
Interior diameter : 30 mm
Exterior diameter : 85 mm
Thickness : 32 mm
Length of wires stator to grommet : 185 mm
Length of wires grommet to terminals : 355 mm
Length of pickup coil’s wire to grommet : 78 mm
Other specifications :
Number of wires : 3
Number of pins : 3
Wire to wire resistance :
Alternator : Yellow to Ground = 0.4 ohms +-20%
Pickup : Blue/Yellow to Ground = 120 ohms +-20%
Source : Black/Red to Ground = 500 ohms +-20%
Voltage Regulator Rectifier Dimensions:
Width : 45 mm
Length : 45 mm
Height: 20 mm
Other specifications :
Number of pins : 2
Minimum Charging Voltage: 13 V +/- 0.5 V
Maximum Charging Current: 6 A – 10 A / 50 W – 200 W
Open Circuit Voltage: <15 V
Operation Temperature: -20⁰ to 85⁰
Please note : this regulator has two wires, yellow to power and black to ground.
Available on backorder
Brand new Kit Lighting Stator + AC Voltage Regulator Rectifier
- All item pictures are accurate; if in doubt, do not hesitate to compare our item to your original part
- All products shipped are tested
Brand new aftermarket stator
- Direct replacement to your original unit
- Plug-and-play, direct fit, easy installation
- Highest grade of lamination materials
- Highest grade of copper winding, resistant to 200 degrees Celsius
- Pick up pulsar coil included
- Rubber grommet included
Heavy Duty AC Voltage Regulator Rectifier
- 12 Volts regulator used by Baja winners
- Heavy duty and improved regulator rectifier
- For use with all standard halogen and quartz lights
- Precise voltage control, eliminates light burnout
- Reduce flickering and dimming
- Simple installation
- Works with all other OEM part
- Rated at 225 watts
Before installing your new Stator:
- Check the AC output of the stator
- Replace any burned or corroded connectors on stator and regulator rectifier
- Check and repair any melted wiring
- Use hi-temp dielectric grease on all connectors
Before installing your new Voltage Regulator Rectifier:
- Check the AC output of the stator
- Replace any burned or corroded connectors on stator and regulator rectifier
- Check and repair any melted wiring
- Use hi-temp dielectric grease on all connectors
Our stator might have a different wire color code than your original part.
All the wires are installed in the correct order; please do not change any of the wiring configurations.
This stator is designed as a direct plug-in replacement and should be used as such.
When bolting stator in, always use locking compound.
If our stator includes a pickup coil, always make sure the air gap is correct upon installation; we suggest as close as possible but no less than 0.010″.
To add headlights to your vehicle:
- The stator includes a 100 watts lighting coil between the yellow wire and the ground
- Ground the black wire from the regulator to the frame
- Connect both yellow wires from the regulator and the lights to the yellow wire from the stator
- Ground the other side of your lights to the frame to complete the circuit
| Weight | 0.50 kg |
|---|---|
| Dimensions | 33.02 × 25.4 × 22.86 cm |
| Brand |
RMSTATOR |
| Fitment Type |
Guaranteed Fit |
OEM AND OTHER PART NUMBER
OEM NUMBER
- 31120-GN1-691, 31120GN1.691, 31120 GN1 691, 31120GN1691
- 31120-KN4-751, 31120.KN4.751, 31120 KN4 751, 31120KN4751
ADDITIONAL NUMBER
- RMS900-106771
