RMS900-108303 | Kit Stator + CDI Module for Ski-Doo Skandic 500 / 503 SWT | Lynx 6900 FCE / Forest 440 1996-2003 | 420886605 / 420965757 |
C$487.78
Stator:
Dimensions:
Interior diameter: 44 mm
Exterior diameter: 96 mm
Thickness: 21 mm
Length of wires stator to terminals: 180 mm & 220 mm
Other specifications:
Number of wires: 5
Number of plugs: 1
Number of pins: 6
Number of poles: 12
Wire to wire resistance:
Alternator: Yellow to Yellow/Black = 0.7 ohms +/-20%
Alternator: Yellow to ground = O.L
Source: Green to White = 258 ohms +/-20%
CDI Ignition Module:
Dimensions:
Height: 41 mm
Length: 47.5 mm
Width: 75.5 mm
Fixation holes center to center: 71 mm
Wires length: 620 mm 600 mm 105 mm
Other specifications:
Number of plugs: 1
Number of wires: 4
Number of pins: 4
Please note that: The only real way to test your CDI box is to swap it out with another known good unit from the same year / make / model. Because of this, we recommend that you rule everything else out before replacing the CDI box.
Available on backorder
Brand new aftermarket stator + CDI ignition module
All products shipped are tested
All item pictures are accurate; if in doubt, do not hesitate to compare our items to your original parts.
Stator:
- You must re-install your original connector and grommet
- Once your connector and grommet are re-installed, our part becomes a plug-and-play unit, direct fit, and very easy to install.
- Highest grade of lamination materials
- Highest grade of copper winding, resistant to 200 degrees Celsius.
- Back Plate included
CDI Ignition Module:
- Direct replacement to your original unit
- Plug-and-play, direct fit, easy installation
- Spark plug cap(s) included
- Higher grade of electric components.
Before installing your new stator + CDI ignition module
- Check the AC output of the stator.
- Replace any burned or corroded connectors on stator and regulator/rectifier
- You must re-install your original connector and grommet
- Check and repair any melted wiring.
- Use hi-temp dielectric grease on all connectors
Our stator may use a different wire color code than your original.
All the wires are installed in the correct order; please do not change any of the wiring configurations.
This stator is designed as a direct plug-in replacement and should be used as such.
When bolting stator in, always use locking compound.
If our stator includes a pickup coil, always make sure the air gap is correct upon installation; we suggest as close as possible but no less than 0.010″.
| Weight | 1.10 kg |
|---|---|
| Dimensions | 33.02 × 5.08 × 22.86 cm |
| Brand |
RMSTATOR |
| Fitment Type |
Guaranteed Fit |
OEM AND OTHER PART NUMBER
OEM PART NUMBER
- 108303-R00, 108303.R00, 108303 R00, 108303R00
OTHER PART NUMBER
- RMS900-108303
